TES DESIGN:  THERMAL ENERGY STORAGE OVERVIEW

TES is a way of producing cooling (or heating) at one point in time and using that heat or cold at another. Common TES systems include the storage of chilled water or hot water in a tank.

With a properly designed thermal energy storage system, Goss Engineering can help you:

      • Reduce Equipment Size (Chillers, Cooling Towers, and Pumps)
      • Reduce Overall Energy Consumption
      • Lower Energy Costs
      • Reduce Maintenance Costs

TES systems are generally either full storage or partial storage systems. TES systems gain their major economic advantage from the difference between on-peak (daytime) and off-peak (night-time) electric energy rates and demand charges. Since electricity is the primary energy source often used for cooling, chilled water TES is more common than hot water TES (heating is generally fueled by natural gas, which is not subject to time-of-use price differentials).

Full storage systems provide all the cooling from the TES system during a certain part of the day (generally on-peak hours) with cooling equipment shut off. During other hours, the cooling equipment is operating at higher load than required to meet the instantaneous load, with the cooling surplus stored.

Partial storage systems typically operate chillers at a constant rate over the full day. Peak loads are met utilizing a mix of stored cooling plus instantaneous chiller produced cooling. During lighter loads, the excess capacity from the chiller is stored.

Though full storage systems can achieve greater energy cost savings than partial storage systems, the amount of cooling equipment and TES capacity (and thus the capital cost) is generally greater with full storage systems than with a partial storage system.

BACK TO TOP OF PAGE




GOSS ENGINEERING

TEXTBOOK  ON   TES  SYSTEMS  BY  LUCAS  B.  HYMAN,  P.E., LEED – AP

Sustainable Thermal Storage Systems: Planning Design and Operations

A practical guide on how to plan, design, and construct sustainable thermal storage systems.

  • Defines sustainable thermal storage
  • Discusses the types of facilities that can benefit from thermal storage
  • Outlines the various types of thermal storage systems available
  • Presents the key requirements in thermal storage planning
  • Includes thermal storage system sizing examples
  • Contains performance metrics
  • Explains how to conduct a feasibility study
  • Features case studies that demonstrate real-world applications

cover of thermal energy storage textbook Use of thermal storage—also called thermal energy storage (TES)—can result in: reduced on-peak electric demand; reduced energy costs; smaller required chiller capacity to meet peak cooling demand; lower capital costs; lower life cycle costs; improved operational flexibility; less air pollution. This book covers all of these aspects.

Read Chapter 1 Online

Download Chapter 1 as PDF file

COMPLETE COVERAGE:

  • Overview
  • Applicability of Thermal Storage Systems
  • Types of Thermal Storage Systems
  • Sensible Thermal Storage Systems
  • Latent Thermal Storage Systems
  • Heat Storage Systems
  • Thermal Storage Sizing
  • Conducting a Feasibility Study
  • Thermal Storage System Design Applications
  • Control Strategies and Requirements
  • Thermal Storage Specifications and Construction Process
  • Commissioning
  • Operations and Optimization
  • Case Study: Chilled Water Storage at Linda University;
  • Case Study: Ice Storage System

Click here  to find this book in online bookstores around the world.
(Online book links offered in cooperation with Global-Find-A-Book.)

ABOUT THE AUTHOR:

Lucas B. Hyman, P.E., LEED-AP, is one of the co-founders of Goss Engineering, Inc. A professional mechanical engineer with nearly 30 years’ experience, he has planned and designed thermal energy storage (TES) systems, central heating and cooling plants, cogeneration plants, and other mechanical systems. Hyman has participated as a mechanical engineer member in value engineering project reviews, conducted and led forensic engineering studies, and served as an expert witness. He is coauthor of Sustainable On-Site CHP Systems: Design, Construction, and Operations (2009).

BACK TO TOP OF PAGE
